REED R2310 Infrared Thermometer, 12:1, 1202°F (650°C)


REED R2310 Offers

This infrared thermometer features a 12:1 distance to spot ratio and has been drop tested up to 9.8ft (3M). The R2310 has the ability to track maximum, minimum, average and differential readings and the ability to set high/low alarms and monitor continuously.


  • Built-in laser pointer identifies target area
  • User selectable °F or °C
  • 12:1 distance to spot size ratio
  • Digitally adjustable emissivity
  • Max, Min, Average and Differential readings
  • Backlit display
  • High and low alarms
  • Dustproof and Drop tested
  • Trigger lock for continuous monitoring
  • Low battery indication and auto shut off

REED R2310 Specifications

Temperature Range -31 to 1202°F (-35 to 650°C)

Accuracy ≥32°F (0°C):±3.6°F (1.8°C) or ±1.8% rdg.,whichever is greater

<32°F (0°C:±3.6°F+0.1°F (1.8°C+0.1°C)/rdg.

Resolution 0.1°F (0.1°C)

Optical Resolution (D:S) 12:1

Spectral Response 8 to 14µm

Emissivity 0.1 to 1.0 (Adjustable)

Response Time 250ms

Backlit Display Yes

Display Hold Yes

High/Low Alarms Yes

Alarm Indicators LED (High: Red, Low: Blue)

Max/Min Yes

Average and Differential Yes

°F/°C Switchable Yes

Trigger Lock Yes

Tripod Mountable Yes

Drop Tested Yes, 9.8' (3M)

Laser Type Class II

Low Battery Indicator Yes

Power Supply 9V battery

Battery Life Approx. 10 hours (with continuous use, backlight on)

Product Certifications CE, RoHS, IP65, Drop Tested

Operating Temperature 32 to 122°F (0 to 50°C)

Storage Temperature -4 to 140°F (-20 to 60°C)

Operating Humidity Range 10 to 90%

Maximum Operating Altitude 6561' (2000m)

Maximum Storage Altitude 39370' (12000m)

Dimensions 7.4 x 4.7 x 2.2" (189 x 118 x 55mm)

Weight 10.3oz (292g)

What's included with the REED R2310

  • Infrared Thermometer
  • Carrying Case
  • Battery
